IGBT Active Rectifier
Part Number
A300484
System Description
This is a for railway applications where single-phase AC power is supplied to high power loads by overhead lines.
Specifications
| IGBT Active Rectifier Specifications | A300484 |
|---|---|
| Power Rated Input | 405 kW |
| Power Rated Output | 500 kW |
| Frequency Range Input | 58 – 62 Hz |
| Frequency Range Output | DC |
| Voltage Range Input | 400 – 600 V rms |
| Voltage Range Output | 850 V |
| Amps Rated Power Input | 950A rms |
| Amps Rated Power Output | 588A |
