Separate Field Armature Module
Part Number
A300791
System Description
Separate Field, liquid cooled, armature allows for faster speeds as required by freight locomotives. The modules are used to control the armature of a DC traction motor.
Specifications
| Separate Field Armature Module Specifications | A300791 |
|---|---|
| Power Rated Input | 750 kW |
| Power Rated Output | 747 kW |
| Frequency Range Input | DC |
| Frequency Range Output | DC |
| Voltage Range Input | 600 – 750 V |
| Voltage Range Output | 0 – input |
| Amps Rated Power Input | 1000 A |
| Amps Rated Power Output | 1000 A |
