Low Voltage Power System
Part Number
A520016
System Description
An air cooled, 38V DC power supply operating from a nominal 600V DC supply. It provides low voltage DC output (LVDC) from high voltage DC (HVDC), using CANbus communication.
Specifications
| Low Voltage Power System Specifications | A520016 |
|---|---|
| Power Rated Input | 7.1 kW @ 600 V |
| Power Rated Output | 6.5 kW @ 38 V |
| Frequency Range Input | DC |
| Frequency Range Output | DC |
| Voltage Range Input | 450 – 750 V |
| Voltage Range Output | 38 V |
| Amps Rated Power Input | 11.8 A @ 7.1 kW |
| Amps Rated Power Output | 173 A @ 6.6 kW |
